TWO POST STEEL RACKS
Overview
Nitrotel Two Post Rack come in 22, 28, 42 & 45U,SPCC, Cold Rolled Steel, Finished with Electrostatic Paint, Color Black RAL 9005
Key Features
- U” shaped rails (3″ x 3/16″) tapped both front and rear with EIA
- compliant RMS spacing
- Open frame rack meets or exceeds EIA-310D standards
- Complete with assembly hardware and set of #12-24 tapped equipment screws
- Rosh’s certificate
Specifications
| Part number | U/RM S | Height | Width | Out Side deepth | Load Capacity | Weight |
| NTFR2P28USTBK | 28 | 4’ | 19″ | 13″ | 500 lbs | 22 lbs |
| NTFR2P42USTBK | 42 | 7’ | 19″ | 13″ | 800 lbs | 26 lbs |
| NTFR2P45USTBK | 45 | 7’ | 19″ | 13″ | 800 lbs | 29 lbs |
| NTFR2P48USTBK | 48 | 7,5’ | 19″ | 13″ | 900 lbs | 32 lbs |
